4mm 1.5 Mm Thick Decorative Aluminium Sheet Anodized Aluminum Coil H14
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | Alumetal |
| Model Number: | Aluminum coil |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 Tons |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | wooden pallet |
|
Detail Information |
|||
| Product Name: | High Quality PE/PVDF 0.08-0.5mm Thick Color Coated Aluminum Coil | Width: | <1800mm |
|---|---|---|---|
| Core Material: | Nontoxic Polyethylene | Panel Thickness: | 3mm 4mm 5mm 6mm |
| Standard Size: | 1220mm*2440mm*3mm/4mm/5mm/6mm | Surface Treatment: | Coated |
| Temper: | O - H112 | Aluminum Alloy: | 1100 / 3003 |
| Standard Width: | 1220/1250/1500/1570 | Coil Thickness: | 0.08-0.5mm |
| High Light: | 4mm decorative aluminium sheet,decorative aluminium sheet H14,1.5mm thick anodized aluminum coil |
||
Product Description
High Quality PE/PVDF 0.08-0.5mm Thick Color Coated Aluminum Coil
Aluminum coil has many features.
1.The temperature resistance is good. The melting point of aluminum is 660 degrees, and the general temperature does not reach its melting point. 2.Environmental protection. Not easy to turn yellow, using chromium-free treatment liquid to make up for the defects of easy discoloration of the laminating board; the roller paint contains active chemical molecules, which promotes the formation of a protective layer on the surface of the material. Active chemical molecules are stable and easy to recycle, meeting environmental requirements. 3.Corrosion resistance. Because of its tight surface oxide film, it has strong adhesion, oxidation resistance, acid resistance, alkali resistance, corrosion resistance, decay resistance and UV resistance. 4.color uniform, long-lasting, its color is even and delicate. Soft and colorful, avoiding the individual chromatic aberration of traditional spraying, no matter how large the ceiling, its color and color are consistent. Lasting and new. 5.rigid joint, the strength of the board is extremely high. Rigid and tough combination, free to cut, slit, arc, balance, drilling, joint fixation and edge compression molding.
| Alloy | Thickness | Width | Temper |
| A1050, A1060, A1070, A1100 | 0.2MM~200MM | 10MM~2500MM | O, H12, H22, H14, H16, H18, H24, H26, etc |
| A3003, A3105, A3004 | 0.2MM~200MM | 10MM~2500MM | O, H14, H18, H24, etc |
| A5052, A5005, A5083, A5754 | 0.2MM~200MM | 10MM~2500MM | O, H14, H18, H24, etc |
| A6061, A6082, A6063 | 0.2MM~200MM | 10MM~2500MM | T4, T6, T651, etc |
| A8011 | 0.2MM~200MM | 10MM~2500MM | O, H12, H22, H14, H16, H18, H24, H26, etc |
| Production Process | Cold Rolled, Hot Rolled |
| Internal Diameter | 150mm, 305mm, 405mm, 505mm or per request |
| Coil Weight | 2-4 tons |
| Standard | ASTM-B209, EN573-1, GB/T3880.1-2006 |
| Color | Alumetal color and customized color as sample, Ral or Pantone |
| Color Standard | E<2 or it is not obvious by eyeballing |
| Coating | PE, PVDF, Epoxy |
| Coating Thickness | PVDF>=25 micron POLYESTER>=18 micron |
| Coating Adhesive | Not lower than first grade impact: no any crack (50kg/cm, ASTM D-2794:1993) |
| MOQ | 5~8 Tons (According to specification) |
| Delivery Time | Future goods: 20~30 work days, ready stock: 7-10 days. |
| Quality of Material | Totally free from detects like white rust, roll marks, edge damage, camber, dents, holes, break lines, scratches and free from coil set. |
| Pencil Hardness | >2HB |
| Bend Strength | >100 times |
| Boiling Point | No any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours) |
| Corrosive | Surface deep in the 5% muriatic acid and 5% NaCl, interior deep in the 2% muriatic acid and 2% NaCl, after 48 hours, no change |
| Package | Export wooden pallets, craft paper. The bundle weight not exceed 2 MT, Loading: by 1x20GP |
Click Below to Download Color Chart
Alumetal Color Chart.pdf
Q1. What is the minimum order quantity?
500Sq M for aluminium composite panel for one color with 1220 mm*2440 mm size.
Q2. What is your terms of payment?
T/T 30% deposit in advance; the balance paid should be paid according to the copy of B/L.
Q3. How about your delivery time?
Generally, it will take 15to 20days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
Yes, we can produce by your samples or technical drawings.
Q5. Why can I trust you and place order with you?
1. We are manufacture and supplier of aluminum composite panel in china with over 10 years's experience.
2. We keep fastest delivery. Since we have perfect production equipment.
